RunAnywhere Kotlin SDK Part 3: Text-to-Speech with Piper

Natural Voice Synthesis Entirely On-Device

This is Part 3 of our RunAnywhere Kotlin SDK tutorial series:

Chat with LLMs — Project setup and streaming text generation
Speech-to-Text — Real-time transcription with Whisper
Text-to-Speech (this post) — Natural voice synthesis with Piper
Voice Pipeline — Full voice assistant with VAD

Text-to-speech brings your app to life. With RunAnywhere, you can synthesize natural-sounding speech using Piper—completely on-device, with no network latency.

The SDK returns audio data that can be played using Android's AudioTrack for direct playback.

Prerequisites

Complete Part 1 first to set up your project with the RunAnywhere SDK
~65MB additional storage for the Piper voice model

Register the TTS Voice

Add Piper to your model registration in RunAnywhereApp.kt:

kotlin

1import com.runanywhere.sdk.core.types.InferenceFramework
2import com.runanywhere.sdk.public.extensions.Models.ModelCategory
3import com.runanywhere.sdk.public.extensions.registerModel
4
5// Register TTS voice (Piper)
6RunAnywhere.registerModel(
7    id = "vits-piper-en_US-lessac-medium",
8    name = "Piper US English",
9    url = "https://github.com/RunanywhereAI/sherpa-onnx/releases/download/runanywhere-models-v1/vits-piper-en_US-lessac-medium.tar.gz",
10    framework = InferenceFramework.ONNX,
11    modality = ModelCategory.SPEECH_SYNTHESIS,
12    memoryRequirement = 65_000_000
13)

Important: Piper Output Format

Piper outputs audio in a specific format:

Parameter	Value
Sample Rate	22,050 Hz
Channels	1 (mono)
Format	WAV audio bytes

The SDK handles the conversion internally and returns playable WAV data.

Audio Playback Service

Create TTSAudioPlayer.kt:

kotlin

1package com.example.localaiplayground.domain.services
2
3import android.media.AudioAttributes
4import android.media.AudioFormat
5import android.media.AudioManager
6import android.media.AudioTrack
7import android.util.Log
8import kotlinx.coroutines.Dispatchers
9import kotlinx.coroutines.withContext
10
11class TTSAudioPlayer {
12    companion object {
13        private const val TAG = "TTSAudioPlayer"
14        private const val SAMPLE_RATE = 22050  // Piper outputs at 22.05kHz
15    }
16
17    private var audioTrack: AudioTrack? = null
18
19    suspend fun playAudio(audioData: ByteArray) = withContext(Dispatchers.IO) {
20        try {
21            stop()  // Stop any current playback
22
23            // Skip WAV header if present (first 44 bytes)
24            val pcmData = if (isWavFile(audioData)) {
25                audioData.copyOfRange(44, audioData.size)
26            } else {
27                audioData
28            }
29
30            val bufferSize = AudioTrack.getMinBufferSize(
31                SAMPLE_RATE,
32                AudioFormat.CHANNEL_OUT_MONO,
33                AudioFormat.ENCODING_PCM_16BIT
34            )
35
36            audioTrack = AudioTrack.Builder()
37                .setAudioAttributes(
38                    AudioAttributes.Builder()
39                        .setUsage(AudioAttributes.USAGE_MEDIA)
40                        .setContentType(AudioAttributes.CONTENT_TYPE_SPEECH)
41                        .build()
42                )
43                .setAudioFormat(
44                    AudioFormat.Builder()
45                        .setEncoding(AudioFormat.ENCODING_PCM_16BIT)
46                        .setSampleRate(SAMPLE_RATE)
47                        .setChannelMask(AudioFormat.CHANNEL_OUT_MONO)
48                        .build()
49                )
50                .setBufferSizeInBytes(maxOf(bufferSize, pcmData.size))
51                .setTransferMode(AudioTrack.MODE_STATIC)
52                .build()
53
54            audioTrack?.apply {
55                write(pcmData, 0, pcmData.size)
56                play()
57
58                // Wait for playback to complete
59                val durationMs = (pcmData.size / 2 * 1000L) / SAMPLE_RATE
60                Thread.sleep(durationMs)
61
62                stop()
63                release()
64            }
65
66            Log.d(TAG, "Playback complete: ${pcmData.size} bytes")
67
68        } catch (e: Exception) {
69            Log.e(TAG, "Playback error", e)
70            throw e
71        }
72    }
73
74    fun stop() {
75        try {
76            audioTrack?.apply {
77                if (playState == AudioTrack.PLAYSTATE_PLAYING) {
78                    stop()
79                }
80                release()
81            }
82            audioTrack = null
83        } catch (e: Exception) {
84            Log.w(TAG, "Error stopping playback", e)
85        }
86    }
87
88    private fun isWavFile(data: ByteArray): Boolean {
89        return data.size > 44 &&
90               data[0] == 'R'.code.toByte() &&
91               data[1] == 'I'.code.toByte() &&
92               data[2] == 'F'.code.toByte() &&
93               data[3] == 'F'.code.toByte()
94    }
95}

TTS ViewModel

Create TextToSpeechViewModel.kt:

kotlin

1package com.example.localaiplayground.presentation.tts
2
3import android.app.Application
4import androidx.lifecycle.AndroidViewModel
5import androidx.lifecycle.viewModelScope
6import com.example.localaiplayground.domain.services.TTSAudioPlayer
7import com.runanywhere.sdk.public.RunAnywhere
8import com.runanywhere.sdk.public.extensions.TTS.TTSOptions
9import com.runanywhere.sdk.public.extensions.availableModels
10import com.runanywhere.sdk.public.extensions.downloadModel
11import com.runanywhere.sdk.public.extensions.isTTSVoiceLoaded
12import com.runanywhere.sdk.public.extensions.loadTTSVoice
13import com.runanywhere.sdk.public.extensions.synthesize
14import com.runanywhere.sdk.public.extensions.unloadTTSVoice
15import kotlinx.coroutines.flow.*
16import kotlinx.coroutines.launch
17
18data class TTSUiState(
19    val isLoading: Boolean = true,
20    val isModelLoaded: Boolean = false,
21    val downloadProgress: Float = 0f,
22    val isSynthesizing: Boolean = false,
23    val speechRate: Float = 1.0f,
24    val pitch: Float = 1.0f,
25    val error: String? = null
26)
27
28class TextToSpeechViewModel(application: Application) : AndroidViewModel(application) {
29    private val _uiState = MutableStateFlow(TTSUiState())
30    val uiState: StateFlow<TTSUiState> = _uiState.asStateFlow()
31
32    private val audioPlayer = TTSAudioPlayer()
33    private val modelId = "vits-piper-en_US-lessac-medium"
34
35    init {
36        loadModel()
37    }
38
39    private fun loadModel() {
40        viewModelScope.launch {
41            try {
42                val models = RunAnywhere.availableModels()
43                val isDownloaded = models.any { it.id == modelId && it.localPath != null }
44
45                if (!isDownloaded) {
46                    RunAnywhere.downloadModel(modelId).collect { progress ->
47                        _uiState.update {
48                            it.copy(downloadProgress = progress.progress)
49                        }
50                    }
51                }
52
53                // Load TTS voice
54                RunAnywhere.loadTTSVoice(modelId)
55
56                _uiState.update {
57                    it.copy(isLoading = false, isModelLoaded = true)
58                }
59
60            } catch (e: Exception) {
61                _uiState.update {
62                    it.copy(isLoading = false, error = e.message)
63                }
64            }
65        }
66    }
67
68    fun setSpeechRate(rate: Float) {
69        _uiState.update { it.copy(speechRate = rate) }
70    }
71
72    fun setPitch(pitch: Float) {
73        _uiState.update { it.copy(pitch = pitch) }
74    }
75
76    fun synthesizeAndPlay(text: String) {
77        if (text.isBlank() || _uiState.value.isSynthesizing) return
78
79        viewModelScope.launch {
80            _uiState.update { it.copy(isSynthesizing = true, error = null) }
81
82            try {
83                val options = TTSOptions(
84                    rate = _uiState.value.speechRate,
85                    pitch = _uiState.value.pitch,
86                )
87
88                val result = RunAnywhere.synthesize(text, options)
89
90                // result.audioData contains WAV bytes
91                audioPlayer.playAudio(result.audioData)
92
93            } catch (e: Exception) {
94                _uiState.update { it.copy(error = e.message) }
95            } finally {
96                _uiState.update { it.copy(isSynthesizing = false) }
97            }
98        }
99    }
100
101    override fun onCleared() {
102        super.onCleared()
103        audioPlayer.stop()
104    }
105}

TTS Screen

Create TextToSpeechScreen.kt:

kotlin

1package com.example.localaiplayground.presentation.tts
2
3import androidx.compose.foundation.background
4import androidx.compose.foundation.layout.*
5import androidx.compose.foundation.shape.RoundedCornerShape
6import androidx.compose.material3.*
7import androidx.compose.runtime.*
8import androidx.compose.ui.Alignment
9import androidx.compose.ui.Modifier
10import androidx.compose.ui.graphics.Color
11import androidx.compose.ui.unit.dp
12import androidx.lifecycle.viewmodel.compose.viewModel
13
14@Composable
15fun TextToSpeechScreen(
16    viewModel: TextToSpeechViewModel = viewModel()
17) {
18    val uiState by viewModel.uiState.collectAsState()
19    var inputText by remember {
20        mutableStateOf("Hello! This is text-to-speech running entirely on your device.")
21    }
22
23    Column(
24        modifier = Modifier
25            .fillMaxSize()
26            .background(Color.Black)
27            .padding(24.dp)
28    ) {
29        // Loading state
30        if (uiState.isLoading) {
31            Box(
32                modifier = Modifier.fillMaxSize(),
33                contentAlignment = Alignment.Center
34            ) {
35                Column(horizontalAlignment = Alignment.CenterHorizontally) {
36                    CircularProgressIndicator()
37                    Spacer(modifier = Modifier.height(16.dp))
38                    Text(
39                        "Downloading voice model... ${(uiState.downloadProgress * 100).toInt()}%",
40                        color = Color.White
41                    )
42                    LinearProgressIndicator(
43                        progress = { uiState.downloadProgress },
44                        modifier = Modifier
45                            .fillMaxWidth()
46                            .padding(top = 8.dp)
47                    )
48                }
49            }
50            return
51        }
52
53        // Text input
54        OutlinedTextField(
55            value = inputText,
56            onValueChange = { inputText = it },
57            modifier = Modifier
58                .fillMaxWidth()
59                .height(150.dp),
60            label = { Text("Text to speak") },
61            colors = OutlinedTextFieldDefaults.colors(
62                focusedTextColor = Color.White,
63                unfocusedTextColor = Color.White,
64                focusedLabelColor = Color.White,
65                unfocusedLabelColor = Color.Gray,
66                focusedBorderColor = Color(0xFF007AFF),
67                unfocusedBorderColor = Color.Gray
68            )
69        )
70
71        Spacer(modifier = Modifier.height(24.dp))
72
73        // Speed slider
74        Text(
75            "Speed: ${String.format("%.1f", uiState.speechRate)}x",
76            color = Color.White
77        )
78        Slider(
79            value = uiState.speechRate,
80            onValueChange = { viewModel.setSpeechRate(it) },
81            valueRange = 0.5f..2.0f,
82            steps = 15,
83            modifier = Modifier.fillMaxWidth()
84        )
85
86        Spacer(modifier = Modifier.height(16.dp))
87
88        // Pitch slider
89        Text(
90            "Pitch: ${String.format("%.1f", uiState.pitch)}",
91            color = Color.White
92        )
93        Slider(
94            value = uiState.pitch,
95            onValueChange = { viewModel.setPitch(it) },
96            valueRange = 0.5f..1.5f,
97            steps = 10,
98            modifier = Modifier.fillMaxWidth()
99        )
100
101        Spacer(modifier = Modifier.height(32.dp))
102
103        // Speak button
104        Button(
105            onClick = { viewModel.synthesizeAndPlay(inputText) },
106            modifier = Modifier
107                .fillMaxWidth()
108                .height(56.dp),
109            enabled = uiState.isModelLoaded && !uiState.isSynthesizing && inputText.isNotBlank(),
110            shape = RoundedCornerShape(12.dp)
111        ) {
112            if (uiState.isSynthesizing) {
113                CircularProgressIndicator(
114                    modifier = Modifier.size(24.dp),
115                    color = Color.White,
116                    strokeWidth = 2.dp
117                )
118                Spacer(modifier = Modifier.width(8.dp))
119                Text("Synthesizing...")
120            } else {
121                Text("🔊 Speak")
122            }
123        }
124
125        // Error display
126        uiState.error?.let { error ->
127            Spacer(modifier = Modifier.height(16.dp))
128            Text(
129                text = error,
130                color = Color.Red,
131                modifier = Modifier.padding(8.dp)
132            )
133        }
134    }
135}

Memory Management

When you're done with TTS, unload the voice:

kotlin

1// Unload TTS voice
2RunAnywhere.unloadTTSVoice()

TTS voices can be loaded independently alongside the LLM and STT models—they don't conflict.

Models Reference

Model ID	Size	Notes
vits-piper-en_US-lessac-medium	~65MB	Natural US English

What's Next

In Part 4, we'll combine everything into a complete voice assistant with automatic Voice Activity Detection.

Resources

Questions? Open an issue on GitHub or reach out on Twitter/X.
