RunAnywhere Flutter SDK Part 4: Building a Voice Assistant with VAD

1┌─────────────────────────────────────────────────────────────────┐
2│                     Voice Assistant Pipeline                      │
3├─────────────────────────────────────────────────────────────────┤
4│                                                                   │
5│   ┌─────────┐    ┌─────────┐    ┌─────────┐    ┌─────────┐      │
6│   │  Record │ -> │   STT   │ -> │   LLM   │ -> │   TTS   │      │
7│   │  + VAD  │    │ Whisper │    │  LFM2   │    │  Piper  │      │
8│   └─────────┘    └─────────┘    └─────────┘    └─────────┘      │
9│       │                                              │           │
10│       │          Auto-stop when                      │           │
11│       └──────────  silence detected  ────────────────┘           │
12│                                                                   │
13└─────────────────────────────────────────────────────────────────┘

1import 'dart:async';
2import 'dart:typed_data';
3import 'package:flutter/foundation.dart';
4import 'package:runanywhere/runanywhere.dart';
5import '../../services/audio_recording_service.dart';
6import '../../services/audio_playback_service.dart';
7
8enum PipelineState {
9  idle,
10  listening,
11  transcribing,
12  thinking,
13  speaking,
14}
15
16class VoicePipeline extends ChangeNotifier {
17  final AudioRecordingService _audioService = AudioRecordingService();
18  final AudioPlaybackService _playbackService = AudioPlaybackService();
19
20  PipelineState _state = PipelineState.idle;
21  String _transcribedText = '';
22  String _responseText = '';
23  String? _errorMessage;
24  Timer? _vadTimer;
25
26  // VAD thresholds (tune these for your environment)
27  static const double speechThreshold = 0.02;   // Level to detect speech start
28  static const double silenceThreshold = 0.01;  // Level to detect speech end
29  static const double silenceDuration = 1.5;    // Seconds of silence before auto-stop
30
31  // VAD state
32  bool _isSpeechDetected = false;
33  DateTime? _silenceStartTime;
34
35  PipelineState get state => _state;
36  String get transcribedText => _transcribedText;
37  String get responseText => _responseText;
38  String? get errorMessage => _errorMessage;
39
40  Future<void> start() async {
41    if (_state != PipelineState.idle) return;
42
43    // Ensure all models are loaded
44    final isReady = await _isReady();
45    if (!isReady) {
46      _errorMessage = 'Models not loaded. Please load LLM, STT, and TTS first.';
47      notifyListeners();
48      return;
49    }
50
51    _state = PipelineState.listening;
52    _transcribedText = '';
53    _responseText = '';
54    _errorMessage = null;
55    notifyListeners();
56
57    try {
58      await _audioService.startRecording();
59
60      // Start energy-based VAD monitoring
61      _startVADMonitoring();
62
63    } catch (e) {
64      _errorMessage = e.toString();
65      _state = PipelineState.idle;
66      notifyListeners();
67    }
68  }
69
70  void _startVADMonitoring() {
71    _isSpeechDetected = false;
72    _silenceStartTime = null;
73
74    _vadTimer = Timer.periodic(
75      const Duration(milliseconds: 100),
76      (_) => _checkAudioLevel(),
77    );
78  }
79
80  void _checkAudioLevel() {
81    final amplitude = _audioService.getAmplitude();
82
83    // Detect speech start
84    if (!_isSpeechDetected && amplitude > speechThreshold) {
85      _isSpeechDetected = true;
86      _silenceStartTime = null;
87      debugPrint('Speech detected');
88    }
89
90    // Detect speech end (only after speech was detected)
91    if (_isSpeechDetected) {
92      if (amplitude < silenceThreshold) {
93        _silenceStartTime ??= DateTime.now();
94
95        final elapsed = DateTime.now().difference(_silenceStartTime!).inMilliseconds;
96        if (elapsed >= (silenceDuration * 1000).toInt()) {
97          debugPrint('Auto-stopping after silence');
98          _stopVADMonitoring();
99          _processRecording();
100        }
101      } else {
102        _silenceStartTime = null; // Speech resumed
103      }
104    }
105  }
106
107  void _stopVADMonitoring() {
108    _vadTimer?.cancel();
109    _vadTimer = null;
110  }
111
112  Future<void> stopManually() async {
113    _stopVADMonitoring();
114    await _processRecording();
115  }
116
117  Future<void> _processRecording() async {
118    if (_state != PipelineState.listening) return;
119
120    // 1. Stop recording and get audio
121    _state = PipelineState.transcribing;
122    notifyListeners();
123
124    try {
125      final audioData = await _audioService.stopRecording();
126
127      if (audioData == null || audioData.isEmpty) {
128        _state = PipelineState.idle;
129        notifyListeners();
130        return;
131      }
132
133      // 2. Transcribe
134      final text = await RunAnywhere.transcribe(audioData);
135      _transcribedText = text;
136      notifyListeners();
137
138      if (text.trim().isEmpty) {
139        _state = PipelineState.idle;
140        notifyListeners();
141        return;
142      }
143
144      // 3. Generate LLM response
145      _state = PipelineState.thinking;
146      notifyListeners();
147
148      final prompt = '''
149You are a helpful voice assistant. Keep responses SHORT (2-3 sentences max).
150Be conversational and friendly.
151
152User: $text
153Assistant:''';
154
155      final options = LLMGenerationOptions(
156        maxTokens: 100,
157        temperature: 0.7,
158      );
159
160      final streamResult = await RunAnywhere.generateStream(prompt, options: options);
161
162      String response = '';
163      await for (final token in streamResult.stream) {
164        response += token;
165        _responseText = response;
166        notifyListeners();
167      }
168
169      // 4. Speak the response
170      _state = PipelineState.speaking;
171      notifyListeners();
172
173      final ttsResult = await RunAnywhere.synthesize(
174        response,
175        rate: 1.0,
176        pitch: 1.0,
177        volume: 1.0,
178      );
179
180      await _playbackService.playFloat32Audio(
181        ttsResult.samples,
182        ttsResult.sampleRate,
183      );
184
185      // Wait for audio to finish (approximate)
186      await Future.delayed(Duration(
187        milliseconds: (ttsResult.duration * 1000).toInt() + 500,
188      ));
189
190    } catch (e) {
191      debugPrint('Pipeline error: $e');
192      _errorMessage = e.toString();
193    }
194
195    _state = PipelineState.idle;
196    notifyListeners();
197  }
198
199  Future<bool> _isReady() async {
200    return RunAnywhere.isModelLoaded &&
201           RunAnywhere.isSTTModelLoaded &&
202           RunAnywhere.isTTSVoiceLoaded;
203  }
204
205  @override
206  void dispose() {
207    _stopVADMonitoring();
208    _audioService.dispose();
209    super.dispose();
210  }
211}

1import 'package:flutter/material.dart';
2import 'package:provider/provider.dart';
3import 'voice_pipeline.dart';
4
5class VoiceAssistantView extends StatelessWidget {
6  const VoiceAssistantView({super.key});
7
8  @override
9  Widget build(BuildContext context) {
10    return ChangeNotifierProvider(
11      create: (_) => VoicePipeline(),
12      child: const _VoiceAssistantContent(),
13    );
14  }
15}
16
17class _VoiceAssistantContent extends StatelessWidget {
18  const _VoiceAssistantContent();
19
20  @override
21  Widget build(BuildContext context) {
22    final pipeline = context.watch<VoicePipeline>();
23
24    return Scaffold(
25      appBar: AppBar(
26        title: const Text('Voice Assistant'),
27      ),
28      body: Padding(
29        padding: const EdgeInsets.all(24),
30        child: Column(
31          children: [
32            // State indicator
33            _StateIndicator(state: pipeline.state),
34
35            const SizedBox(height: 24),
36
37            // Error message
38            if (pipeline.errorMessage != null)
39              Container(
40                padding: const EdgeInsets.all(12),
41                decoration: BoxDecoration(
42                  color: Colors.red.withOpacity(0.1),
43                  borderRadius: BorderRadius.circular(8),
44                ),
45                child: Text(
46                  pipeline.errorMessage!,
47                  style: const TextStyle(color: Colors.red),
48                ),
49              ),
50
51            // Transcription
52            if (pipeline.transcribedText.isNotEmpty)
53              _ConversationBubble(
54                label: 'You said:',
55                text: pipeline.transcribedText,
56                color: Colors.blue,
57              ),
58
59            const SizedBox(height: 16),
60
61            // Response
62            if (pipeline.responseText.isNotEmpty)
63              _ConversationBubble(
64                label: 'Assistant:',
65                text: pipeline.responseText,
66                color: Colors.green,
67              ),
68
69            const Spacer(),
70
71            // Main button
72            _MainButton(
73              state: pipeline.state,
74              onPressed: () {
75                if (pipeline.state == PipelineState.idle) {
76                  pipeline.start();
77                } else if (pipeline.state == PipelineState.listening) {
78                  pipeline.stopManually();
79                }
80              },
81            ),
82
83            const SizedBox(height: 16),
84
85            Text(
86              _getStateHint(pipeline.state),
87              style: TextStyle(
88                color: Colors.grey[600],
89                fontSize: 12,
90              ),
91            ),
92          ],
93        ),
94      ),
95    );
96  }
97
98  String _getStateHint(PipelineState state) {
99    switch (state) {
100      case PipelineState.idle:
101        return 'Tap to start';
102      case PipelineState.listening:
103        return 'Stops automatically when you pause';
104      case PipelineState.transcribing:
105        return 'Converting speech to text...';
106      case PipelineState.thinking:
107        return 'Generating response...';
108      case PipelineState.speaking:
109        return 'Playing audio response...';
110    }
111  }
112}
113
114class _StateIndicator extends StatelessWidget {
115  final PipelineState state;
116
117  const _StateIndicator({required this.state});
118
119  @override
120  Widget build(BuildContext context) {
121    return Row(
122      mainAxisAlignment: MainAxisAlignment.center,
123      children: [
124        Container(
125          width: 12,
126          height: 12,
127          decoration: BoxDecoration(
128            shape: BoxShape.circle,
129            color: _getStateColor(),
130          ),
131        ),
132        const SizedBox(width: 8),
133        Text(
134          _getStateText(),
135          style: const TextStyle(
136            fontSize: 16,
137            fontWeight: FontWeight.w500,
138          ),
139        ),
140      ],
141    );
142  }
143
144  Color _getStateColor() {
145    switch (state) {
146      case PipelineState.idle:
147        return Colors.grey;
148      case PipelineState.listening:
149        return Colors.red;
150      case PipelineState.transcribing:
151      case PipelineState.thinking:
152        return Colors.orange;
153      case PipelineState.speaking:
154        return Colors.green;
155    }
156  }
157
158  String _getStateText() {
159    switch (state) {
160      case PipelineState.idle:
161        return 'Ready';
162      case PipelineState.listening:
163        return 'Listening...';
164      case PipelineState.transcribing:
165        return 'Transcribing...';
166      case PipelineState.thinking:
167        return 'Thinking...';
168      case PipelineState.speaking:
169        return 'Speaking...';
170    }
171  }
172}
173
174class _ConversationBubble extends StatelessWidget {
175  final String label;
176  final String text;
177  final Color color;
178
179  const _ConversationBubble({
180    required this.label,
181    required this.text,
182    required this.color,
183  });
184
185  @override
186  Widget build(BuildContext context) {
187    return Container(
188      width: double.infinity,
189      padding: const EdgeInsets.all(16),
190      decoration: BoxDecoration(
191        color: color.withOpacity(0.1),
192        borderRadius: BorderRadius.circular(12),
193      ),
194      child: Column(
195        crossAxisAlignment: CrossAxisAlignment.start,
196        children: [
197          Text(
198            label,
199            style: TextStyle(
200              color: Colors.grey[600],
201              fontSize: 12,
202            ),
203          ),
204          const SizedBox(height: 4),
205          Text(
206            text,
207            style: const TextStyle(fontSize: 16),
208          ),
209        ],
210      ),
211    );
212  }
213}
214
215class _MainButton extends StatelessWidget {
216  final PipelineState state;
217  final VoidCallback onPressed;
218
219  const _MainButton({
220    required this.state,
221    required this.onPressed,
222  });
223
224  @override
225  Widget build(BuildContext context) {
226    final isActive = state == PipelineState.idle || state == PipelineState.listening;
227
228    return GestureDetector(
229      onTap: isActive ? onPressed : null,
230      child: Container(
231        width: 80,
232        height: 80,
233        decoration: BoxDecoration(
234          shape: BoxShape.circle,
235          color: state == PipelineState.idle ? Colors.blue : Colors.red,
236        ),
237        child: Icon(
238          state == PipelineState.idle ? Icons.mic : Icons.stop,
239          size: 36,
240          color: Colors.white,
241        ),
242      ),
243    );
244  }
245}

1// Download and load all models sequentially
2await modelService.downloadAndLoadLLM();
3await modelService.downloadAndLoadSTT();
4await modelService.downloadAndLoadTTS();

1// Unload when not needed
2await RunAnywhere.unloadModel();
3await RunAnywhere.unloadSTTModel();
4await RunAnywhere.unloadTTSVoice();

1Future<void> start() async {
2  if (_state != PipelineState.idle) return;  // Prevent double-starts
3  // ...
4}

1static const double speechThreshold = 0.05;   // Higher for noisy environments
2static const double silenceThreshold = 0.02;  // Higher for noisy environments
3static const double silenceDuration = 2.0;    // Longer pause tolerance

1bool get isVoiceAgentReady {
2  return RunAnywhere.isModelLoaded &&
3         RunAnywhere.isSTTModelLoaded &&
4         RunAnywhere.isTTSVoiceLoaded;
5}

1final session = await RunAnywhere.startVoiceSession(
2  config: VoiceSessionConfig(
3    autoDetectSilence: true,
4    silenceThreshold: 1.5,
5  ),
6);
7
8session.events.listen((event) {
9  if (event is VoiceSessionTranscribed) {
10    debugPrint('User said: ${event.text}');
11  } else if (event is VoiceSessionResponded) {
12    debugPrint('AI response: ${event.text}');
13  }
14});
