RunAnywhere Swift SDK Part 2: Speech-to-Text with Whisper

Real-Time Transcription with On-Device Whisper

This is Part 2 of our RunAnywhere Swift SDK tutorial series:

Chat with LLMs — Project setup and streaming text generation
Speech-to-Text (this post) — Real-time transcription with Whisper
Text-to-Speech — Natural voice synthesis with Piper
Voice Pipeline — Full voice assistant with VAD

Speech recognition unlocks natural interaction with your app. With RunAnywhere, you can run Whisper entirely on-device—no network requests, no privacy concerns, no API costs.

But there's a catch that trips up most developers: audio format conversion. iOS microphones don't output audio in the format Whisper expects. This tutorial covers both the API and the critical audio handling.

Prerequisites

Complete Part 1 first to set up your project with the RunAnywhere SDK
Physical iOS device required — the iOS Simulator doesn't have microphone access
~75MB additional storage for the Whisper model

Register the STT Model

Add Whisper to your model registration:

swift

1// Register STT model (Whisper)
2RunAnywhere.registerModel(
3    id: "sherpa-onnx-whisper-tiny.en",
4    name: "Whisper Tiny English",
5    url: URL(string: "https://github.com/RunanywhereAI/sherpa-onnx/releases/download/runanywhere-models-v1/sherpa-onnx-whisper-tiny.en.tar.gz")!,
6    framework: .onnx,
7    modality: .speechRecognition,
8    artifactType: .archive(.tarGz, structure: .nestedDirectory),
9    memoryRequirement: 75_000_000
10)

Critical: Audio Format Requirements

This is where most tutorials fail you. Whisper requires a very specific audio format:

Parameter	Required Value
Sample Rate	16,000 Hz
Channels	1 (mono)
Format	16-bit signed integer (Int16) PCM

But iOS microphones record at 48,000 Hz in Float32 format. You MUST resample.

Setting Up Audio Conversion

swift

1import AVFoundation
2
3class AudioService: ObservableObject {
4    private let audioEngine = AVAudioEngine()
5    private var audioConverter: AVAudioConverter?
6    private let dataLock = NSLock()  // Thread safety for audio callbacks
7    private var recordedData = Data()
8
9    private let targetFormat = AVAudioFormat(
10        commonFormat: .pcmFormatInt16,
11        sampleRate: 16000,
12        channels: 1,
13        interleaved: true
14    )!
15
16    enum AudioError: Error {
17        case converterCreationFailed
18        case engineStartFailed
19    }
20
21    func startRecording() throws {
22        let session = AVAudioSession.sharedInstance()
23        try session.setCategory(.playAndRecord, mode: .default)
24        try session.setActive(true)
25
26        let inputNode = audioEngine.inputNode
27        let inputFormat = inputNode.outputFormat(forBus: 0) // Usually 48kHz Float32
28
29        // Create converter from iOS format to Whisper format
30        guard let converter = AVAudioConverter(from: inputFormat, to: targetFormat) else {
31            throw AudioError.converterCreationFailed
32        }
33        audioConverter = converter
34
35        dataLock.lock()
36        recordedData = Data()
37        dataLock.unlock()
38
39        inputNode.installTap(onBus: 0, bufferSize: 4096, format: inputFormat) { [weak self] buffer, _ in
40            self?.processAudioBuffer(buffer)
41        }
42
43        try audioEngine.start()
44    }
45
46    private func processAudioBuffer(_ inputBuffer: AVAudioPCMBuffer) {
47        guard let converter = audioConverter else { return }
48
49        // Calculate output frame count based on sample rate ratio
50        let ratio = targetFormat.sampleRate / inputBuffer.format.sampleRate
51        let outputFrameCount = AVAudioFrameCount(Double(inputBuffer.frameLength) * ratio)
52
53        guard let outputBuffer = AVAudioPCMBuffer(
54            pcmFormat: targetFormat,
55            frameCapacity: outputFrameCount
56        ) else { return }
57
58        var error: NSError?
59        let status = converter.convert(to: outputBuffer, error: &error) { inNumPackets, outStatus in
60            outStatus.pointee = .haveData
61            return inputBuffer
62        }
63
64        if status == .haveData, let int16Data = outputBuffer.int16ChannelData {
65            let data = Data(bytes: int16Data[0], count: Int(outputBuffer.frameLength) * 2)
66            // Thread-safe append (audio callback runs on audio thread)
67            dataLock.lock()
68            recordedData.append(data)
69            dataLock.unlock()
70        }
71    }
72
73    func stopRecording() -> Data {
74        audioEngine.stop()
75        audioEngine.inputNode.removeTap(onBus: 0)
76
77        dataLock.lock()
78        let data = recordedData
79        dataLock.unlock()
80
81        // Deactivate audio session when done
82        try? AVAudioSession.sharedInstance().setActive(false)
83
84        return data
85    }
86}

Important: The resampling step is non-negotiable. Sending 48kHz audio to Whisper will produce garbage output or crash.

Thread Safety: The processAudioBuffer callback runs on the audio thread, not the main thread. We use NSLock to safely append data. In production, consider using a lock-free ring buffer for better performance.

Loading and Using STT

swift

1// Download the model (one-time, ~75MB)
2if !(await RunAnywhere.isModelDownloaded("sherpa-onnx-whisper-tiny.en")) {
3    let progressStream = try await RunAnywhere.downloadModel("sherpa-onnx-whisper-tiny.en")
4    for await progress in progressStream {
5        print("Download: \(Int(progress.overallProgress * 100))%")
6        if progress.stage == .completed { break }
7    }
8}
9
10// Load STT model into memory
11try await RunAnywhere.loadSTTModel("sherpa-onnx-whisper-tiny.en")
12
13// Transcribe audio data (must be 16kHz Int16 PCM!)
14let audioData = audioService.stopRecording()
15let text = try await RunAnywhere.transcribe(audioData)
16print("Transcription: \(text)")

Why loadSTTModel() instead of loadModel()? The SDK uses separate methods for each modality: loadModel() for LLMs, loadSTTModel() for speech-to-text, and loadTTSVoice() for text-to-speech. This reflects that each uses a different runtime (LlamaCPP vs ONNX) and can be loaded simultaneously without conflicts.

Complete Recording Flow

Here's how to wire it up in a SwiftUI view:

swift

1struct SpeechToTextView: View {
2    @StateObject private var audioService = AudioService()
3    @State private var isRecording = false
4    @State private var transcription = ""
5    @State private var isTranscribing = false
6
7    var body: some View {
8        VStack(spacing: 24) {
9            // Transcription display
10            Text(transcription.isEmpty ? "Tap to record..." : transcription)
11                .font(.body)
12                .padding()
13                .frame(maxWidth: .infinity, minHeight: 100)
14                .background(Color.secondary.opacity(0.1))
15                .cornerRadius(12)
16
17            // Record button
18            Button(action: toggleRecording) {
19                Image(systemName: isRecording ? "stop.circle.fill" : "mic.circle.fill")
20                    .font(.system(size: 64))
21                    .foregroundColor(isRecording ? .red : .blue)
22            }
23            .disabled(isTranscribing)
24
25            if isTranscribing {
26                ProgressView("Transcribing...")
27            }
28        }
29        .padding()
30    }
31
32    private func toggleRecording() {
33        if isRecording {
34            stopAndTranscribe()
35        } else {
36            startRecording()
37        }
38    }
39
40    private func startRecording() {
41        do {
42            try audioService.startRecording()
43            isRecording = true
44        } catch {
45            print("Failed to start recording: \(error)")
46        }
47    }
48
49    private func stopAndTranscribe() {
50        isRecording = false
51        let audioData = audioService.stopRecording()
52
53        Task {
54            isTranscribing = true
55            do {
56                transcription = try await RunAnywhere.transcribe(audioData)
57            } catch {
58                transcription = "Error: \(error.localizedDescription)"
59            }
60            isTranscribing = false
61        }
62    }
63}

Memory Management

When you're done with STT, unload the model to free memory:

swift

1// Unload STT model (no parameters needed)
2try await RunAnywhere.unloadSTTModel()

STT models can be loaded independently alongside the LLM—they don't conflict.

Models Reference

Model ID	Size	Notes
sherpa-onnx-whisper-tiny.en	~75MB	English, real-time capable

What's Next

In Part 3, we'll add text-to-speech with Piper, including the inverse audio conversion challenge.

Resources

Questions? Open an issue on GitHub or reach out on Twitter/X.
